Gravity Paddy Separator Machine with Single Body for brown rice and
Paddy
Working Principle:
The gravity separation screen is to make use of the physical
characteristics differences of the specific gravity, friction
coefficient and grain size of the brown rice and rice in the
mixture. Under the action of the separation plate with sinusoidal
motion, the mixture of the brown rice and the coarse rice will be
gradually stratified automatically, and the coarse rice with larger
and smaller particle size will sink down, and will be pushed upward
by the convex point of the separation plate, so that the brown rice
will move up the separation plate obliquely Out. The rice with
small specific gravity and large grain size floats on the upper
layer of brown rice and glides obliquely down to the lower part of
the separation plate to flow out, so as to achieve the effect of
grain rough separation.
New Single Product, Three Major Features:
1. Stainless steel separation sieve plate, smooth surface, durable,
not dry bran, wide range of application, strong separation ability.
2. Can adapt to the separation of long and short grain rice rough.
low energy consumption, low noise.
3. Large unit screening area and high output (consistent with
single side output of double gravity grain rougher).
| Model | YTMGCZ60x20 | YTMGCZ60x24 | YTMGCZ46x20 |
| Layers of Separating Plate | 20x1 | 24x1 | 20x1 |
| Output of Pure Brown Rice | 4-5t/h | 3-4t/h | 2-3t/h |
| Grain Contented In Pure Brown Rice: ≤5(grain/kg) |
| Re-hulls Contain Brown Rice: ≤10% |
| Volume of Re-hulling and Pure Brown Rice: about 15% |
| Suction Volume of Dedusting: 170x2(m3/h) |
| Weight | 700kg | 650 | 600kg |
| Power | 3kw | 2.2kw | 2.2kw |
| Overall LxWxH | 1330x1780x2250 | 1330x1780x2130 | 1230x1735x2250 |
| Note: The above technical data can be changed without notice. |
