30 Tons Soybean Batch Grain Dryer / Grain Dryer Machine Steel Material

30tons Tower Grain Dryer,Soybean Grain Dryer Machine,batch grain dryer

Feature:

1. The belt and bucket of elevator use Zhenjiang Sanwei Brand with large capacity polymer material bucket, the reliability is high. Lower linear speed effectively reduces the crushing rate in conveying process.

2. The drying part use 201SS ,side plate use famous brand 1.2mm cold rolled palte.

Technical Specifications of 30T Grain Dryers
Model			YTGD30
Type			Batch type circulation
Volume(t)	Paddy(560kg/m3)		30
	Wheat(680kg/m3)		28.5
Outer Dimension(mm)LxWxH			5650x3199x14194
Handling Capacity (kg/h) (range of moisture reduction from 25% to 14.5%)			≥1500
Hot Resources			Burner(diesel or natural gas),Husker burner(coal,husk,branch or biomass),Boiler(steam or conduction oil) etc.
Husk Burner	Type		Gun type,high voltage spray
	Ignition Mode		Automatic high voltage ignition
	Natural Gas Consumption		17-32(m3/h)
	Husk Consumption		20-30(kg/h)
Fuel			Coal,husk,branch,biomass,high clean kerosene,diesel or natural gas
Blower Motor Power (kw)			11
The Total Power of Motor(kw)/ Voltage(v)			15.12/380
Time of Feeding(min)		Paddy	55-65
		Wheat	60-70
Time of Discharging(min)		Paddy	51-61
		Wheat	57-67
Moisture Reduction Rate Per Hour		Paddy	0.4-1.0％
		Wheat	0.4-1.0%
Automatic Control and Safety Device		Automatic moisture meter, automatic ignition, automatic stop, temperature control device, fault alarm device, full grain alarm device, electrical overload protection device, leakage protection device
The moisture reduction rate listed above is reference value. Effected by the air temperature outside, relative humidity, the variety of drying and so on, the actual value will be a little different.No notice will be given if there is a change for specification, dimension and color.

To learn more about this machine, please visit: www.riceprocessingplant.com,and our facebook page.

If you have any questions,please feel free to contact us.
